89
CHAPTER2 PROFIBUS Unit
(23) Arrangement element specification
of counter arrangement variable C ....................................... Code 0117
The arrangement elements of the counter arrangement variable C used are speci-
fied.
Command option
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
Arrangement
element No.
Command response
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
(Details)
Arrangement element No.:
It expresses the inherent number of 0 to 31 to specify the arrange-
ment element of the counter arrangement variable.
If 65534 (=FFFE (hexadecimal)) is input here, the value in the
counter variable "D" is used to specify the element of the counter
variable.
(Example)
Transmission example 1:
Hereafter, the counter arrangement variable of the element No. 1
is used.
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
QWn+10
QWn+8
0000
0000 0000
0000
0000 0001
0000 0117
Response example 1:
It is normally ended.
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
IWm+10
IWm+8
0000
0000 0000
0000
0000 0000
0000 0200
