ELECTRICAL COMPONENTS (YUM1A/YUM2A)
8-59
c. Measure the fuel injector resistance.
CHECKING THE OIL LEVEL SWITCH
1. Check:
• Engine oil level
• Refer to “CHECKING THE ENGINE OIL
LEVEL (YUM1A/YUM2A)” on page 3-4.
2. Check:
• Oil level switch
Out of specification → Replace.
a. Check the oil level switch for no continuity.
b. Drain the engine oil.
c. Check the oil level switch for continuity.
Digital circuit tester (CD732)
90890-03243
Model 88 Multimeter with ta-
chometer
YU-A1927
• Positive tester probe
Fuel injector terminal “1”
• Negative tester probe
Fuel injector terminal “2”
Engine oil is at the correct level
No continuity
(Between “1” and ground)
Engine oil is drained
Continuity
(Between “1” and ground)
To Next Page
