TIGHTENING TORQUES
2-18
Front wheel hub nut M16 2 162 N·m (16.2 kgf·m, 116 lb·ft)
Rear wheel nut M12 8 102 N·m (10.2 kgf·m, 75 lb·ft)
Rear wheel hub nut 3/4 2 210 N·m (21 kgf·m, 155 lb·ft)
Front brake plate nut (YUM2A/
YUM2E)
M8 8 41 N·m (4.1 kgf·m, 30 lb·ft)
Rear brake plate nut M8 8 42 N·m (4.2 kgf·m, 31 lb·ft)
Brake cable adjusting locknut
(YUM1A)
M8 1 17 N·m (1.7 kgf·m, 13 lb·ft)
Brake cable adjusting locknut
(YUM2A/YUM2E)
M8 2 17 N·m (1.7 kgf·m, 13 lb·ft)
Pedal assembly bolt M8 6 16 N·m (1.6 kgf·m, 12 lb·ft)
Accelerator switch screw M5 2 3.8 N·m (0.38 kgf·m, 2.8 lb·ft)
Throttle position sensor screw
(YUM2E)
M5 2 3.6 N·m (0.36 kgf·m, 2.7 lb·ft)
Throttle position sensor bracket bolt
(YUM2E)
M5 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Accelerator pedal bolt M6 1 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Parking brake release bolt locknut M8 1 16 N·m (1.6 kgf·m, 12 lb·ft)
Brake rod locknut M6 1 6 N·m (0.6 kgf·m, 4.4 lb·ft)
Brake pedal arm bolt M10 1 48 N·m (4.8 kgf·m, 35 lb·ft)
Brake pedal nut M6 1 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Parking brake pedal nut M8 1 23 N·m (2.3 kgf·m, 17 lb·ft)
Parking brake pedal cover nut M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Latch plate bolt M8 2 16 N·m (1.6 kgf·m, 12 lb·ft)
Steering column bolt M8 4 22 N·m (2.2 kgf·m, 16 lb·ft)
Steering joint bolt M8 2 22 N·m (2.2 kgf·m, 16 lb·ft)
Tie-rod end nut M12 2 39 N·m (3.9 kgf·m, 29 lb·ft)
Tie-rod — 2 75 N·m (7.5 kgf·m, 55 lb·ft)
Tie-rod nut M12 2 45 N·m (4.5 kgf·m, 33 lb·ft)
Steering assembly bolt M10 4 52 N·m (5.2 kgf·m, 38 lb·ft)
Steering knuckle arm nut M10 4 63 N·m (6.3 kgf·m, 47 lb·ft)
Steering knuckle nut M10 2 55 N·m (5.5 kgf·m, 41 lb·ft)
Front shock absorber assembly up-
per nut
M10 2 73 N·m (7.3 kgf·m, 54 lb·ft)
Front shock absorber assembly low-
er nut
M12 2 80 N·m (8.0 kgf·m, 59 lb·ft)
Front lower arm nut M10 4 47 N·m (4.7 kgf·m, 35 lb·ft)
Front under bracket nut M10 4 47 N·m (4.7 kgf·m, 35 lb·ft)
Rear shock absorber assembly up-
per nut
M12 2 125 N·m (12.5 kgf·m, 92 lb·ft)
Rear shock absorber assembly low-
er nut
M12 2 125 N·m (12.5 kgf·m, 92 lb·ft)
Stabilizer joint nut M10 4 64 N·m (6.4 kgf·m, 47 lb·ft)
Stabilizer holder bolt M8 4 30 N·m (3.0 kgf·m, 22 lb·ft)
Item
Thread
size
Q’ty Tightening torque Remarks
