Yamaha WR450F(T) - Description; General Information

GEN
INFO
1 - 1
DESCRIPTION
EC100000
GENERAL INFORMATION
EC110000
DESCRIPTION
1
Clutch lever
2
Hot starter lever
3
“ENGINE STOP” button
4
Trip meter
5
Main switch
6
Start switch
7
Front brake lever
8
Throttle grip
9
Radiator cap
0
Fuel tank cap
A
Taillight
B
Kickstarter
C
Fuel tank
D
Headlight
E
Radiator
F
Coolant drain bolt
G
Rear brake pedal
H
Valve joint
I
Fuel cock
J
Cold starter knob
K
Air cleaner
L
Drive chain
M
Shift pedal
N
Oil dipstick
O
Front fork
N
OTE:
• The machine you have purchased may differ
slightly from those shown in the following.
• Designs and specifications are subject to
change without notice.
