(8) Remove the center plate section (B) from
section (A) using a wrench, and take it out.
CAUTION
Be careful because the center plate section (B) is
heavy and it will be slippery because it is covered
in oil.
IMPORTANT
Replace the oil seal (A) on the engine side of the
clutch housing with a new one when
reassembling the unit.
To prevent the oil seal from deforming due to the
weight of the center plate section (B), reinstall the
oil seal from the clutch side after reinstalling the
center plate section (B).
To Next Page
