Yanmar EF-494T - REMOVING THE SEAT STAY

2 DISASSEMBLY OF COMPONENTS 2 DISASSEMBLY OF COMPONENTS
EF494T TM 06/2011 edition
45
2.4 REMOVING THE SEAT STAY
Note:
It is necessary to remove the fuel tank.
(1) Remove the seat, lever knobs (A), and
housing cover (B) (M6x16: 8 pieces.).
(B)
(2) Remove fender.
Refer “2.2 REMOVING THE FENDER”.
(3) Drain the fuel from the fuel tank. Fuel can be
drained easily from section (A).
