0.3.3 SCREW TIGHTENING TORQUE TABLE
Tighten screws, bolts and nuts according to the table below. If the tightening torque is specified, follow
the specification.
General tightening torque Unit: N-m (kgf-m)
Items
Thread diameter
Tightening torque
PT plug
1/8
9.8 (1.0)
1/4
19.6 (2.0)
3/8
29.4 (3.0)
1/2
58.8 (6.0)
Pipe joint bolt
M8
13.0 - 16.4 (1.3 - 1.7)
M12
24.5 - 34.3 (2.5 - 3.5)
M14
39.2 - 49.0 (4.0 - 5.0)
M16
49.0 - 58.8 (5.0 - 6.0)
General tightening torque of bolts N-m (kgf-m)
Standard thread screw
Nominal size
4T
7T
M6
4.90 - 6.86 (0.5 - 0.7)
8 - 12 (0.8 - 1.2)
M8
12.74 - 16.66 (1.3 - 1.7)
23 - 29 (2.3 - 3.0)
M10
24.50 - 34.36 (2.5 - 3.5)
44 - 59 (4.5 - 6.0)
M12
44.10 - 58.80 (4.5 - 6.0)
78 - 98 (8.0 - 10.0)
M14
68.80 - 83.30 (7.0 - 8.5)
118 - 147 (12.0 - 15.0)
M16
107.80 - 137.20 (11.0 - 14.0)
167 - 206 (17.0 - 21.0)
M18
156.80 - 186.20 (16.0 - 19.0)
235 - 284 (24.0 - 29.0)
M20
215.60 - 264.60 (22.0 - 27.0)
324 - 402 (33.0 - 41.0)
IMPORTANT
 The tightening torque of fine thread screws shall be 80% of that of the standard thread
screws.
 To tighten any aluminum part, apply torque equivalent to 80% of the specified value.
 Recently, all the bolts may be standardized to 7T bolts under the plant line management of
Yanmar.
 When 7T bolt is used with rubber, rubber packing or aluminum parts, tighten the bolt
following the values in the 4T-bolt table.
Bolt standard
4T
7T
Tensile Strength (kgf/sq.mm)
Minimum
40
70
Brinell Hardness (Hb)
Minimum
105
201
Maximum
229
277
Yield Point (kgf/sq.mm)
Minimum
23
50
