Yanmar EF-494T - Page 6

TABLE OF CONTENTS TABLE OF CONTENTS
EF494T TM 06/2011 edition
iv
5.4 TRANSMISSION (CLUTCH HOUSING CASE SIDE)
5.4.1 Disassembly
5.4.2 Main shift section
5.5 TRANSMISSION (TRANSMISSION HOUSING
CASE SIDE)
5.5.1 Disassembly
5.5.2 PTO module
114
115
120
121
123
128
6 REAR AXLE AND BRAKE
130
6.1 STRUCTURE AND FUNCTIONS
6.1.1 Structure drawing
6.1.2 Differential system
6.1.3 Final drive system
6.1.4 Brake
6.2 DISASSEMBLY AND ASSEMBLY
6.2.1 Differential system
6.2.2 Rear axle oil seal
6.2.3 Planetary gears and axle shaft
131
131
132
133
134
136
136
137
138
7 FRONT AXLE
139
7.1 STRUCTURE AND FUNCTIONS
7.2 CROSS-SECTION VIEW
7.3 FRONT WHEEL ALIGNMENT
7.4 DISASSEMBLING THE FRONT BEARING CASE
7.5 DISASSEMBLING THE FRONT GEAR BOX
7.6 DISASSEMBLING AND ASSEMBLING THE FRONT
DIFFERENTIAL SECTION
7.6.1 Disassembly
7.6.2 Assembly
140
141
142
143
143
144
144
146
8 POWER STEERING
148
8.1 STRUCTURE AND FUNCTIONS
8.1.1 Structure drawing
8.1.2 Hydraulic circuit
8.1.3 Power steering valve functions
8.1.4 Hydraulic pump
8.1.5 Power steering
8.2 POWER STEERING VALVE
8.2.1 Removing power steering valve assembly
8.2.2 Power steering relief pressure
8.2.3 Disassembly
149
149
150
151
152
153
154
154
155
156
