(2) Reinstall the front wheels, lower the jack,
and tighten the wheel bolts.
IMPORTANT
Wheel bolt torque
177-196 N-m (18.0-20.0 kgf-m, 130-145 lb-ft)
(3) Reinstall the propeller shaft and shaft cover.
IMPORTANT
Put grease into the rubber boots on both
sides.
Replace the split pin (B) with a new one.
There are 6 steel balls (C) on each side.
Be sure to install spacer (E) on rear and front
side. If not, cover may be broken in a short
time.
(A) Mounting bolt
(B) Split pin
(C) Steel balls
To Next Page
