2 DISASSEMBLY OF COMPONENTS 2 DISASSEMBLY OF COMPONENTS
EF494T TM 06/2011 edition
70
cylinder.
(5) Supply oil to the front axle.



(3) Reinstall the propeller shaft and shaft cover.
IMPORTANT
 Put grease into the rubber boots on both
sides.
 Replace the split pin (B) with a new one.
 There are 6 steel balls (C) on each side.
 Be sure to install spacer (E) on rear and front
side. If not, cover may be broken in a short
time.

