Installation 1-7
LED Sequence
Table 1.3 - LED States
LED Label Description
D1 MS/RUN
GREEN - Card Functioning Normally
GREEN BLINK - Standby/Initializing (500ms cycle)
RED BLINK - Minor Fault (500ms cycle)
RED - Major Fault
GREEN/RED BLINK - Module Test (500ms cycle)
D2 NS/CON
GREEN - Connected
GREEN BLINK - Waiting for Connections (500ms cycle)
RED BLINK - Connection Timeout (500ms cycle)
RED - Duplicate IP Address
GREEN/RED BLINK - Network Test (500ms cycle)
D3 10/100 GREEN - 100Mbs Connection Speed
D4 LINK GREEN - Link Established
D5 Rx GREEN - Message Being Received
D8 PWR GREEN - Appropriate Power Supplied to Card
