C Standards Compliance
YASKAWA ELECTRIC TOEP C710616 38H YASKAWA AC Drive-L1000A Quick Start Guide 231
Standards Compliance
C
Closed-Loop Crimp Terminal Recommendations
Yaskawa recommends using closed-loop crimp terminals on all drive models. UL approval requires the use of UL Listed
crimp terminals when wiring the drive main circuit terminals on Models CIMR- LU20085 to 20415, 40045 to
40605, and 50032 to 50200. Use only crimping tools as specified by the crimp terminal manufacturer. Yaskawa
recommends crimp terminals made by JST and Tokyo DIP (or equivalent) for the insulation cap.
Table 65 matches the wire gauges and terminal screw sizes with Yaskawa - recommended crimp terminals, tools, and
insulation caps. Refer to the appropriate Wire Gauge and Torque Specifications table for the wire gauge and screw size
for your drive model. Place orders with a Yaskawa representatives the Yaskawa sales department.
Table 65 Closed-Loop Crimp Terminal Size
50172
R/L1, S/L2, T/L3 300 2/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 250 2/0 to 600
–, +1 – 2/0 to 400
+3 – 2/0 to 250 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
50200
R/L1, S/L2, T/L3 400 2/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 350 2/0 to 600
–, +1 – 2/0 to 500
+3 – 250 to 300 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
Wire Gauge
Terminal
Screws
Crimp Terminal
Model Number
Tool
Insulation Cap
Model No.
Code <1>
Machine No. Die Jaw
14 AWG M4 R2-4 YA-4 AD-900 TP-003 100-054-028
12 / 10 AWG
M4 R5.5-4 YA-4 AD-900 TP-005 100-054-029
M5 R5.5-5 YA-4 AD-900 TP-005 100-054-030
8 AWG
M4 8-4 YA-4 AD-901 TP-008 100-054-031
M5 R8-5 YA-4 AD-901 TP-008 100-054-032
6 AWG
M4 14-NK4 YA-4 AD-902 TP-014 100-054-033
M5 R14-5 YA-4 AD-902 TP-014 100-054-034
M6 R14-6 YA-5 AD-952 TP-014 100-051-261
M8 R14-8 YA-5 AD-952 TP-014 100-054-035
4 AWG
M6 R22-6 YA-5 AD-953 TP-022 100-051-262
M8 R22-8 YA-5 AD-953 TP-022 100-051-263
3/2/1 AWG
M8 R38-8 YA-5 AD-954 TP-038 100-051-264
M10 R38-10 YA-5 AD-954 TP-038 100-061-114
1/0 AWG
1/0 AWG × 2P
M8 R60-8 YA-5 AD-955 TP-060 100-051-265
M10 R60-10 YF-1, YET-300-1 TD-321, TD-311 TP-060 100-051-266
2/0 AWG
2/0 AWG × 2P
M10 70-10 YF-1, YET-300-1 TD-323, TD-312 TP-080 100-054-036
1 AWG × 2P
2 AWG × 2P
M10 38-L10 YF-1, YET-150-1 TD-224, TD-212 TP-038 100-051-556
3/0 AWG M10 80-10 YF-1, YET-300-1 TD-323, TD-312 TP-080 100-051-267
3/0 AWG × 2P
M10 80-L10 YF-1, YET-150-1 TD-227, TD-214 TP-080 100-051-557
M12 80-L12 YF-1, YET-300-1 TD-323, TD-312 TP-080 100-051-558
4/0 AWG M10 R100-10
YF-1, YET-300-1
YF-1, YET-150-1
TD-324, TD-312
TD-228, TD-214
TP-100 100-051-269
Model
CIMR-LU
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
Nm (lb.in.)
