3 Electrical Installation
38 YASKAWA ELECTRIC TOEP C710616 38H YASKAWA AC Drive-L1000A Quick Start Guide
20075
R/L1, S/L2, T/L3 2 10 to 2
M8
9.9 to 11.0
(87.6 to 97.4)
U/T1, V/T2, W/T3 2 10 to 2
–, +1, +2 – 3 to 2
B1, B2 – 6 M5
2.7 to 3.0
(23.9 to 26.6)
66 to 4M6
5.4 to 6.0
(47.8 to 53.1)
20085
R/L1, S/L2, T/L3 1/0 10 to 1/0
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 1/0 10 to 1/0
–, +1 – 2 to 1/0
B1, B2 – 6 to 1/0
66 to 4
20115
R/L1, S/L2, T/L3 2/0 10 to 3/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 2/0 10 to 3/0
–, +1 – 1/0 to 3/0
B1, B2 – 4 to 2/0
44M8
9 to 11
(79.7 to 97.4)
20145
R/L1, S/L2, T/L3 4/0 1/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 4/0 1/0 to 4/0
–, +1 – 1 to 4/0
+3 – 1/0 to 4/0
44 to 2
9 to 11
(79.7 to 97.4)
20180
R/L1, S/L2, T/L3 1/0 × 2P 1/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 1/0 × 2P 1/0 to 4/0
–, +1 – 1 to 4/0
+3 – 1/0 to 4/0
4 4 to 1/0
9 to 11
(79.7 to 97.4)
20215
R/L1, S/L2, T/L3 2/0 × 2P 3/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 2/0 × 2P 3/0 to 300
–, +1 – 3/0 to 300
+3 – 2 to 300 M10
18 to 23
(159 to 204)
3 3 to 300 M12
32 to 40
(283 to 354)
20283
R/L1, S/L2, T/L3 3/0 × 2P 3/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 3/0 × 2P 3/0 to 300
–, +1 – 3/0 to 300
+3 – 3/0 to 300 M10
18 to 23
(159 to 204)
2 2 to 300 M12
32 to 40
(283 to 354)
20346
R/L1, S/L2, T/L3 250 × 2P 4/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 4/0 × 2P 4/0 to 600
–, +1 – 250 to 600
+3 – 3/0 to 600 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
Model
CIMR-LU
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
Nm (lb.in.)
