3 Electrical Installation
YASKAWA ELECTRIC TOEP C710616 38H YASKAWA AC Drive-L1000A Quick Start Guide 37
Electrical Installation
3
Three-Phase 200 V Class
Table 10 Wire Gauge and Torque Specifications (Three-Phase 200 V Class)
Model
CIMR-LU
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
Nm (lb.in.)
20008
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10
<1> 14 to 10
20011
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10
<1> 14 to 10
20014
R/L1, S/L2, T/L3 10 12 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 10 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10
<1> 14 to 10
20018
R/L1, S/L2, T/L3 10 18 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 10 18 to 10
–, +1, +2 – 12 to 10
B1, B2 – 14 to 10
10
<1> 12 to 10
20025
R/L1, S/L2, T/L3 8 12 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 8 12 to 6
–, +1, +2 – 10 to 6
B1, B2 – 12 to 10
8
<2> 10 to 8 M5
2.0 to 2.5
(17.7 to 22.1)
20033
R/L1, S/L2, T/L3 6 12 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 8 12 to 6
–, +1, +2 – 6
B1, B2 – 12 to 10
8 10 to 8 M5
2.0 to 2.5
(17.7 to 22.1)
20047
R/L1, S/L2, T/L3 4 6 to 4
M6
5.4 to 6.0
(47.8 to 53.1)
U/T1, V/T2, W/T3 4 6 to 4
–, +1, +2 – 6 to 4
B1, B2 – 10 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
68 to 6M6
5.4 to 6.0
(47.8 to 53.1)
20060
R/L1, S/L2, T/L3 3 10 to 2
M8
9.9 to 11.0
(87.6 to 97.4)
U/T1, V/T2, W/T3 3 10 to 2
–, +1, +2 – 4 to 3
B1, B2 – 8 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
66 to 4M6
5.4 to 6.0
(47.8 to 53.1)
