4.2 Programming Pendant Specifications
4-3
HW0482738
HW0482738
4.2 Programming Pendant Specifications
Table. 2 Programming Pendant Specifications
Item Specifications
Basic Specifications
Material Reinforced plastic (with strap)
External Dimensions Width: 200 x Height: 300 x Depth: 60 [mm]
Approx. Mass 1.3 kg
Display
Display 6.5 inch
TFT-color LCD
Number of Indication Dots 640 x 480
Operational Panel
Key Switch 54 key switches, arrow key x 1 piece
Touch Panel Touch screen display
Servo On Ready Illuminated push button switch
Emergency Stop Red mushroom type
Push Lock / Turn Reset
Mode Selector Switch among three modes: TEACH, PLAY, REMOTE
3-position select switch
Enable Switch 3-position switch, compliant with EN
Others Hand strap is delivered with the programming pendant.
