• Before operating the manipulator, make sure the servo power is
turned OFF by performing the following operations. When the servo
power is turned OFF, the SERVO ON LED on the programming
pendant is turned OFF.
– Press the emergency stop buttons on the front door of the
YRC1000, on the programming pendant, on the external control
device, etc.
– Disconnect the safety plug of the safety fence.
(when in the play mode and the remote mode)
If operation of the manipulator cannot be stopped in an emergency,
personal injury and/or equipment damage may result.
Fig. : Emergency Stop Button
• Before releasing the emergency stop, make sure to remove the
obstacle or error caused the emergency stop, if any, and then turn
the servo power ON.
Failure to observe this instruction may result in personal injury caused
by unintended manipulator movement.
Fig. : Release of Emergency Stop
• Observe the following precautions when performing a teaching
operation within the P-point maximum envelope of the manipulator:
– Be sure to perform lockout by putting a lockout device on the
safety fence when going into the area enclosed by the safety
fence. In addition, the operator of the teaching operation must
display the sign that the operation is being performed so that no
other person closes the safety fence.
– View the manipulator from the front whenever possible.
– Always follow the predetermined operating procedure.
– Always keep in mind emergency response measures against the
manipulator’s unexpected movement toward a person.
– Ensure a safe place to retreat in case of emergency.
Failure to observe this instruction may result in personal injury caused
by improper or unintended manipulator movement.
• Confirm that no person is present in the P-point maximum envelope
of the manipulator and that the operator is in a safe location before:
– Turning ON the YRC1000 power
– Moving the manipulator by using the programming pendant
– Running the system in the check mode
– Performing automatic operations
Injury may result if any person should enter the P-point maximum
envelope of the manipulator during operation. Immediately press an
emergency stop button whenever there is a problem. The emergency
stop buttons are located on the front panel of the YRC1000 and on the
right of the programming pendant.
• Read and understand the Explanation of the Warning Labels in the
YRC1000 Instructions before operating the manipulator.
