YASKAWA MP2000 Series User Manual

12.2 Troubleshooting System Errors
12.2.4 System Register Configuration and Error Status
12-23
Troubleshooting
[ c ] MP2200 Machine Controller
Name Register No. Description
CPU Information
SW00800
Module ID
CPU-01: (C280H)
CPU-02: (C281H)
SW00801
Reserved by the system
SW00802
CPU Software version (BCD)
SW00803
Number of subslots
CPU-01: (0002H)
CPU-02: (0004H)
SW00804
CPU Function Module ID (C210H)
SW00805
CPU Function Module status
SW00806
SVR Function Module ID (9210H)
SW00807
SVR Function Module status
SW00808
CPU-02: CARD Function Module ID (8170H)
CPU-01:
Reserved by the sys-
tem
SW00809
CPU-02: CARD Function Module status
SW00810
CPU-02: USB Function Module ID (8F20H)
SW00811
CPU-02: USB Function Module status
SW00812 to SW00815
Reserved by the system
Rack 1, Slot 1
Information
SW00816
Module ID
SW00817
Hardware version (HEX)
SW00818
Software version (BCD)
SW00819
Number of subslots
SW00820
Subslot 1 Function Module ID
SW00821
Subslot 1 Function Module status
SW00822
Subslot 2 Function Module ID
SW00823
Subslot 2 Function Module status
Rack 1, Slot 2
Information
SW00824 to SW00831
Same as above
Rack 1, Slot 3
Information
SW00832 to SW00839
Same as above
Rack 1, Slot 4
Information
SW00840 to SW00847
Same as above
Rack 1, Slot 5
Information
SW00848 to SW00855
Same as above
Rack 1, Slot 6
Information
SW00856 to SW00863
Same as above
Rack 1, Slot 7
Information
SW00864 to SW00871
Same as above
Rack 1, Slot 8
Information
SW00872 to SW00879
Same as above
