YASKAWA MP2000 Series User Manual

12.2 Troubleshooting System Errors
12.2.4 System Register Configuration and Error Status
12-24
Rack 2, Slot 1
Information
SW00880
Module ID
SW00881
Hardware version (HEX)
SW00882
Software version (BCD)
SW00883
Number of subslots
SW00884
Subslot 1 Function Module ID
SW00885
Subslot 1 Function Module status
SW00886
Subslot 2 Function Module ID
SW00887
Subslot 2 Function Module status
Rack 2, Slot 2
Information
SW00888 to SW00895
Same as above
Rack 2, Slot 3
Information
SW00896 to SW00903
Same as above
Rack 2, Slot 4
Information
SW00904 to SW00911
Same as above
Rack 2, Slot 5
Information
SW00912 to SW00919
Same as above
Rack 2, Slot 6
Information
SW00920 to SW00927
Same as above
Rack 2, Slot 7
Information
SW00928 to SW00935
Same as above
Rack 2, Slot 8
Information
SW00936 to SW00943
Same as above
Rack 2, Slot 9
Information
SW00944 to SW00951
Same as above
Rack 3, Slot 1
Information
SW00952
Module ID
SW00953
Hardware version (HEX)
SW00954
Software version (BCD)
SW00955
Number of subslots
SW00956
Subslot 1 Function Module ID
SW00957
Subslot 1 Function Module status
SW00958
Subslot 2 Function Module ID
SW00959
Subslot 2 Function Module status
Rack 3, Slot 2
Information
SW00960 to SW00967
Same as above
Rack 3, Slot 3
Information
SW00968 to SW00975
Same as above
Rack 3, Slot 4
Information
SW00976 to SW00983
Same as above
Rack 3, Slot 5
Information
SW00984 to SW00991
Same as above
Rack 3, Slot 6
Information
SW00992 to SW00999
Same as above
Rack 3, Slot 7
Information
SW01000 to SW01007
Same as above
Rack 3, Slot 8
Information
SW01008 to SW01015
Same as above
Rack 3, Slot 9
Information
SW01016 to SW01023
Same as above
(cont’d)
Name Register No. Description
