2 Transport
2.1 Transport Method
2-1
159328-1CD
HW1480497
MS80W Manipulator
2 Transport
2.1 Transport Method
• Sling and crane or forklift operations must be performed by
authorized personnel only.
Failure to observe this caution may result in injury or damage.
• Avoid excessive vibration or shock during transport.
The system consists of precision components. Failure to observe this
caution may adversely affect performance.
• Check that the eyebolts are securely fastened.
• The weight of the manipulator is approximately 610 kg
including the shipping bolts and brackets. Use a wire rope
strong enough to withstand the weight.
• The attached eyebolts are designed to support the
manipulator mass. Never use them for anything other
than transporting the manipulator.
• Mount the shipping bolts and brackets before transporting
the manipulator.
• Avoid putting external force on the arm of motor unit when
transporting by a crane, forklift, or other equipment.
Failure to observe this instruction may result in injury.
