MS80W Manipulator
2 Transport
2.2 Shipping Bolts and Brackets
2.2 Shipping Bolts and Brackets
The manipulator is provided with shipping bolts and brackets at positions
shown in Fig. 2-1 Transport Using a Crane on page 2-2.
• The shipping bolts and brackets are painted yellow.
• Refer to the following table for the shipping bolts and brackets fixing
screws.
Table 2-1: Shipping Bolts and Brackets Fixing Screws
Shipping Bolts and
Bracket Qty.
Shipping Bolts and Bracket Fixing
Screw Specification
Fixing Screw
Qty.
2 Hexagon Socket Head Cap Screw M12
(length: 25 mm)
(Tensile strength: 1200N/mm
2
)
4 screws x
2 places
Before turning ON the power, check to be sure that the
shipping bolts and brackets are removed. The shipping
bolts and brackets then must be stored for future use, in the
event that the manipulator must be moved again.
