MS80W Manipulator
5 Basic Specifications
5.4 Dimensions and P-Point Maximum Envelope
5.4 Dimensions and P-Point Maximum Envelope
Fig. 5-3: Dimensions and P-Point Maximum Envelope
R2236
R718
320
1025
175
90
80
45
155
50
210
870540
873
718
2236
3803
1295 2456
3751
543
242
301
P-point
P-point maximum envelope
