YASKAWA UAK series User Manual

12.2 Parameter Recording Table
12-29
Appendix
21
Pn416
20A9h:14
0000
Torque Related Function
Switch 2
Immediately
Pn417
20A9h:8
2000 3rd Notch Filter Frequency Immediately
Pn418
20A9h:9
70 3rd Notch Filter Q Value Immediately
Pn419
20A9h:10
0 3rd Notch Filter Depth Immediately
Pn41A
20A9h:11
2000 4rd Notch Filter Frequency Immediately
Pn41B
20A9h:12
70 4rd Notch Filter Q Value Immediately
Pn41C
20A9h:13
0 4rd Notch Filter Depth Immediately
Pn430
20AAh:1
150 Torque Limit (Powering) Immediately
Pn431
20AAh:2
150 Torque Limit (Regeneration) Immediately
Pn432
20ABh:1
15 Motor Flux Lower Level Immediately
Pn433
20ABh:2
100
Servo Mode Flux Level
(for High-speed Winding)
Immediately
Pn434
20ABh:3
100
Servo Mode Base Speed Ratio
(for High-speed Winding)
Immediately
Pn435
20ABh:4
100
Servo Mode Flux Level
(for Low-speed Winding)
Immediately
Pn436
20ABh:5
100
Servo Mode Base Speed Ratio
(for Low-speed Winding)
Immediately
Pn43F
20ACh:1
100
Load Ratio Meter Filter Time
Constant
Immediately
Pn456 2146h:4 15
Sweep Torque Reference
Amplitude
Immediately
Pn460 20A9h:7 0101
Notch Filter Adjustment
Switch
Immediately
Pn481 20C8h:1 40
Magnetic Pole Detection
Speed Loop Gain
Immediately
Pn482 20C8h:2 30
Magnetic Pole Detection
Speed Integral Time
Immediately
Pn486 20C8h:4 25
Magnetic Pole Detection
Command Acceleration/
Deceleration Time
Immediately
Pn487 20C8h:5 0
Magnetic Pole Detection
Command Constant Speed
Time
Immediately
Pn488 20C8h:6 100
Magnetic Pole Detection
Command Waiting Time
Immediately
Pn490 20C8h:9 100
Magnetic Pole Detection Load
Level
Immediately
Pn493 20C8h:12 50
Magnetic Pole Detection
Command Speed
Immediately
Pn494 20C8h:13 0.25
Magnetic Pole Detection Vari-
able Range
Immediately
Pn495 20C8h:14 100
Magnetic Pole Detection
Confirmation Torque Refer-
ence
Immediately
Pn498 20C8h:17 10
Polarity Detection Allowable
Error Range
Immediately
Pn499 20C8h:18 15 Reserved (Do not change.) –
Pn49A 20C8h:19 50 Reserved (Do not change.) –
Pn4F0 20ADh:1 10000
1st Positive Projection
Compensation Gain
Immediately
(cont’d)
Parameter
Index
Number
Factory
Setting
Name
When
Enabled
