YASKAWA UAK series User Manual

12 Appendix
12-30
Pn4F1 20ADh:2 0
1st Positive Projection
Compensation Limit Offset
Immediately
Pn4F2 20ADh:3 1000
2nd Positive Projection
Compensation Gain
Immediately
Pn4F3 20ADh:4 0
2nd Positive Projection
Compensation Limit Offset
Immediately
Pn4F4 20ADh:5 0
Positive Projection Compensa-
tion Limit Change Value
Immediately
Pn4F5 20ADh:6 0
Positive Projection Compensa-
tion Limit Clamp Value
Immediately
Pn4F6 20ADh:7 10000
1st Negative Projection
Compensation Gain
Immediately
Pn4F7 20ADh:8 0
1st Negative Projection
Compensation Limit Offset
Immediately
Pn4F8 20ADh:9 1000
2nd Negative Projection
Compensation Gain
Immediately
Pn4F9 20ADh:10 0
2nd Negative Projection
Compensation Limit Offset
Immediately
Pn4FA 20ADh:11 0
Negative Projection
Compensation Limit Change
Val ue
Immediately
Pn4FB 20ADh:12 0
Negative Projection
Compensation Limit Clamp
Val ue
Immediately
Pn4FC 20ADh:13 0
Projection Compensation Tim-
ing Constant
Immediately
Pn501 2100h:1 10 Zero Clamp Level Immediately
Pn502 2100h:2 20 Rotation Detection Level Immediately
Pn503 2100h:3 10
Speed Coincidence Signal
Output Width
Immediately
Pn506 2112h:1 0
Brake Reference
-
Servo OFF
Delay Time
Immediately
Pn507 2112h:2 100
Brake Reference Output Speed
Level
Immediately
Pn508 2112h:4 50
Waiting Time for Brake Signal
When Motor Running
Immediately
Pn50A 2110h:1 1881 Input Signal Selection 1 After restart
Pn50B 2110h:2 8882 Input Signal Selection 2 After restart
Pn511 2110h:3 6543
Probe1, Probe2, HOME Input
Signal setting
After restart
Pn517 2110h:4 0000 OT Function Immediately
Pn51B 2102h:5 1000
Excessive Error Level between
Servomotor and Load Posi-
tions
Immediately
Pn51E 2102h:1 100
Excessive Position Error
Warning Level
Immediately
Pn520 2102h:2 5242880
Excessive Position Error
Alarm Level
Immediately
Pn522 2102h:3 7Positioning Completed WidthImmediately
Pn524 2102h:4 1073741824 NEAR Signal Width Immediately
Pn526 2103h:1 5242880
Excessive Position Error
Alarm Level at Servo ON
Immediately
(cont’d)
Parameter
Index
Number
Factory
Setting
Name
When
Enabled
