2 Compatible Devices
2.2.2 Servomotor
2-14
 Specifications for cable-end connectors to SERVOPACKs
•SERVOPACK for one axis
Note: For other SERVOPACKs, they have screw terminals. For details, refer to 7.2.1 (1) Wire Sizes and Tightening
Torques.
•SERVOPACK for two axes
 Cables
A 600 V heat-resistant vinyl cable is recommended. Select an appropriate size of cable for the motor and the
SERVOPACK used.
For details, refer to 7.1.2 (1) Main Circuit Cable Wiring and 7.2.1 (1) Wire Sizes and Tightening Torques.
SERVOPACK Model
Connector Housing
Model
Electrical Contact
Model
Wire Size Manufacturer
CACR-JU028ACA 1-917807-2 1318697-6 AWG10
Tyco Electronics Japan
G. K .
CACR-JU036ACA DK-5200S-04R DK-5RECLLP1 (D3) AWG8 DDK Ltd.
CACR-JU014DCA 1-917807-2 316041-6 AWG14
Tyco Electronics Japan
G. K .
CACR-JU018DCA DK-5200S-04R DK-5RECMLP1-100 AWG10 DDK Ltd.
SERVOPACK Model Connector Model
Electrical Contact
Model
Wire Size Manufacturer
CACR-JUM23ACA
1-917807-2
316040-6 AWG14
Tyco Electronics Japan
G. K .
CACR-JUM24ACA 316041-6 AWG10
CACR-JUM25ACA 1318697-6 AWG8
CACR-JUM23DCA
1-917807-2 316040-6 AWG14CACR-JUM24DCA
CACR-JUM25DCA
