5.2 AC Reactor
5-7
Peripheral Devices
5
(5) Model: X008022
(6) Model: X008010
Note: This AC reactor does not comply with UL standards. If an AC reactor that complies with UL standards is required,
contact your Yaskawa representative. The dimensional diagrams for AC reactors that comply with UL standards are
different from the above diagrams.
135 max.
3.2
240
150
63
126
110
25
6-terminals for
M10 screws
4-mounting holes
for M8 bolts
Nameplate
Unit: mm
UV
W
XYZ
205 ± 5
UXVYWZ
125 ± 5
150 ± 5
75
160
7
75
13.5
70
70
25
89
65 max. 45
2.3
6-terminals for
M4 screws
4-mounting holes
for M6 bolts
Nameplate
Unit: mm
