EN 34 YASKAWA Europe TOEP C710606 101A - V1000 MMD IP65 Motor Mounted Drive - Quick Start Guide
5 Start Up
5 Start Up
 Drive Setup Procedure
The illustration below shows the basic setup procedure. Each step is explained more detailed
on the following pages.
Install and wire the drive as explained.
Turn the power on.
START
Set/check the basic parameters:
* b1-01, b1-02 for frequency reference and RUN command source
* H1-, H2-, H3-, H4-, H6-oo to configure the I/Os
* Frequency reference values
* C1-, C2- for Acceleration/Deceleration times and S-curves
Run the motor without load, check the operation and verify, if the
upper controller (e.g. PLC, ...) commands to the drive work as
desired.
Connect the load, run the motor and check the operation
Fine tune and set application parameters (e.g. PID, ...) if necessary.
Final check the operation and verify the settings.
Drive is ready to run the application
