Yealink SIP-T46G User Manual

Advanced Phone Features
187
Receiving RTP Stream
You can configure the phone to receive a Real Time Transport Protocol (RTP) stream from the
pre-configured multicast address(es) without involving SIP signaling. You can specify up to 31
multicast addresses that the phone listens to on the network.
Note
How the phone handles incoming multicast paging calls depends on Paging Barge and Paging
Priority Active parameters configured via web user interface.
Paging Barge
The paging barge parameter defines the priority of the voice call in progress. If the priority of an
incoming multicast paging call is lower than that of the active call, it will be ignored
automatically. If Disabled is selected from the pull-down list of Paging Barge, the voice call in
progress will take precedence over all incoming multicast paging calls. Valid values in the
Paging Barge field:
 1 to 31: Define the priority of the active call, 1 with the highest priority, 31 with the lowest.
 Disabled: The voice call in progress will take precedence over all incoming paging calls.
Paging Priority Active
The paging priority active parameter decides how the phone handles incoming multicast paging
calls when there is already a multicast paging call on the phone. If enabled, the phone will
ignore incoming multicast paging calls with lower priorities, otherwise, the phone will answer
incoming multicast paging calls automatically and place the previous multicast paging call on
hold. If disabled, the phone will automatically ignore all incoming multicast paging calls.
To configure multicast listening addresses via web user interface:
1. Click on Directory->Multicast IP.
2. Select the desired value from the pull-down list of Paging Barge.
3. Select the desired value from the pull-down list of Paging Priority Active.
4. Enter the multicast IP address(es) and port number (e.g., 224.5.6.20:10008) which the phone
listens to for incoming RTP multicast in the Listening Address field.
5. (Optional.) Enter the label in the Label field.
Label will appear on the LCD screen when receiving the multicast RTP stream.
6. Select the desired channel to listen from the pull-down list of Channel.
RTP stream is listened in the speakerphone mode by default. If you want to listen the RTP
stream using the engaged audio device (speakerphone, handset or headset), contact your
system administrator for more information.
Fixed volume to play RTP stream for specified paging group is configurable by your system
administrator.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
