TA410/810 User Manual
server”, you should also upload this certificate on IPPBX.
3.2.5 Firewall Rules
Figure 3-18 Firewall Rules
1) General Settings
Table 3-8 Description of Firewall General Settings
Enable the firewall to protect the device. You should reboot the
device to make the firewall run.
Enable this item to drop net ping from remote hosts.
“Drop All” feature, the system will drop all
packets or connection from other hosts if
rules defined. To avoid locking the devices, at least one “TCP”
accept common rule must be created for port used for SSH
access, port used for HTTP access and port sued for CGI
access.
2) Common Rules
There is no default rule; you can create oneas required.
26/55
