16-1
IM 2558A-01EN
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
16.1 Output
Output
AC Voltage
Range Output range Guaranteed
Accuracy Range
1
Resolution Maximum Output
2
Output Resistance
3
100 mV 0 mV to 144.00 mV 1% to 120% 10 µV Approx. 10 Ω
1 V 0 V to 1.4400 V 1% to 120% 100 µV 0.5 A or greater Approx. 6 mΩ
10 V 0 to 14.400 V 1% to 120% 1 mV Approx. 3 A Approx. 6 mΩ
100 V 0 V to 144.00 V 1% to 120% 10 mV Approx. 0.3 A Approx. 6 mΩ
300 V 0 V to 432.0 V 1% to 120% 100 mV Approx. 0.1 A Approx. 6 mΩ
1000 V 0 V to 1440.0 V 1% to 120% 100 mV Approx. 6 mA Approx. 6 mΩ
AC Current
Range Output range Guaranteed
Accuracy Range
1
Resolution Maximum Output
2
100 mA 0 mA to 144.00 mA 1% to 120% 10 µA Approx. 15 V
1 A 0 A to 1.4400 A 1% to 120% 100 µA Approx. 15 V
10 A 0 A to 14.400 A 1% to 120% 1 mA Approx. 3 V
50 A 0 A to 72.00 A 1% to 120% 10 mA Approx. 0.6 V
1 1% to 144% when the output frequency is 50 Hz or 60 Hz.
2 With the voltage or current at 1% to 120% of the range.
3 When <758933> or <758917> is in use; excluding aging and the effects of measurement leads.
Chapter 16 Specifications
