4.3 Entering and Displaying Values
The following methods are available in entering and displaying values depending on the SETUP menu
item.
• Selecting parameters
• Entering values
• Displaying the log
• Executing a function
Selecting Parameters
Turn a deviation dial to select the parameter.
You can use either deviation dial.
Example: ON/OFF, 8 s/16 s/32 s/64 s, etc.
Entering Values
Turn the deviation dials to enter a value.
Turn the deviation dial 1 to enter the tens digit.
Turn the deviation dial 2 to enter the ones digit.
The dial 2 changes the value by 1.
The dial 1 changes the value by 1 or 2 depending on the item.
Carrying over and borrowing occurs automatically. When the upper or lower limit is reached, the value
will no longer change even if you turn the dial further.
Displaying the Log
The availability of logging information and a number indicating the order of logging information are
displayed.
The logging information is indicated on the auxiliary information display (OUTPUT display).
If logging information is available, turn the deviation dial to switch the display.
Example: NO (none), 3.10 (displaying the third one out of 10)
Executing a Function
For items that represent functions that are to be executed, such as INIT and TEST, EXEC is displayed.
Depending on the item, executing the function will initialize the settings or clear the logging information.
You cannot undo it, so make sure it is okay to execute the function in advance.
EXEC display
