IM 2558A-01EN
Thank you for purchasing the 2558A AC Voltage Current Standard.
The 2558A is a stable signal generator that produces the following voltage and current signals.
• AC voltage: 1 mV to 1200 V; frequency: 40 Hz to 1000 Hz
• AC current: 1 mA to 60 A; frequency: 40 Hz to 1000 Hz
This user’s manual explains the features, operating procedures, and handling precautions of the
2558A. To ensure correct use, please read this manual thoroughly before beginning operation. Keep
this manual in a safe place for quick reference in the event that a question arises.
List of Manuals
The following manuals, including this one, are provided as manuals for the 2558A. Please read all
manuals.
Manual Title Manual No. Description
2558A AC Voltage Current Standard
User’s Manual
IM 2558A-01EN This manual. The manual explains the handling
precautions, features, specifications, communication
interfaces, how to operate the 2558A, and so on.
2558A AC Voltage Current Standard IM 2558A-92Z1 Document for China
The “EN” and “Z1” in the manual numbers are the language codes.
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Document No. Description
PIM 113-01Z2 List of worldwide contacts
Notes
• The contents of this manual are subject to change without prior notice as a result of continuing
improvements to the instrument’s performance and functionality. The figures given in this manual
may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your nearest
YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the permission of
YOKOGAWA is strictly prohibited.
• The TCP/IP software of this product and the documents concerning it have been developed/created
by YOKOGAWA based on the BSD Networking Software, Release 1 that has been licensed from
the Regents of the University of California.
High voltage
The 2558A generates sinusoidal of up to 1440 Vrms.
• To prevent electric shock, be sure to read this manual before use.
• Improper operation may lead to serious, life-threatening accidents. Keep this manual
close to the 2558A so that the operator can refer to it anytime.
French
Haute tension
2558A génère un sinusoïdal jusqu'à 1440 Vrms.
• Afin d’éviter tout choc électrique, bien lire le présent manuel avant utilisation.
• Une utilisation incorrecte entrainerait des risques d’accidents graves voire mortels.
Conservez ce manuel à proximité du 2558A, de sorte que l’opérateur puisse le
consulter à tout moment.
2nd Edition: March 2016 (YMI)
All Rights Reserved, Copyright © 2013 Yokogawa Meters & Instruments Corporation
