Page #144 background imageLoading...
Page #144 background image
16-5
IM 2558A-01EN
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
16.4 External Input and Output
Master/Slave Synchronous Operation Input and Output
(Two terminals each; four terminals total)
Item Specifications
Input/output voltage 3 ± 0.1 V (rms), sinusoidal
Frequency range 40 Hz to 1000 Hz
Input impedance Approx. 1 MΩ
Output impedance Approx. 50 Ω
Terminal
Frequency selection
Internal oscillators EXT1 EXT2
Input
cos(I) (EXT1) Not used Used Used
sin(Q) Not used Not used Used
Output
cos(I) Internal cos (I) signal Connect to input terminal cos (I) Connect to input terminal cos (I)
sin(Q) Internal sin (Q) signal Connect to input terminal sin(Q) Connect to input terminal sin(Q)
16.5 Computer Interface
USB for PC Connection
Item Specifications
Number of ports 1
Connector type Type B connector (receptacle)
Electrical and mechanical Conforms to USB Revision 2.0
Supported transfer modes HS (High Speed; 480 Mbps) and FS (Full Speed; 12 Mbps)
Supported protocols USBTMC-USB488 (USB Test and Measurement Class Ver. 1.0)
PC system requirements A PC with a USB port, running the English or Japanese version of Windows 7 (32 bit), Windows
Vista (32 bit), or Windows XP (32 bit, SP2 or later)
Ethernet
Item Specifications
Ports 1
Connector type RJ-45
Electrical and mechanical Conforms to IEEE 802.3
Transmission system 100BASE-TX/10BASE-T
Transfer rate 100 Mbps max.
Protocol TCP-IP
Supported services VXI-11, DHCP
GP-IB (/C1 Option)
Item Specifications
Electrical and mechanical Conforms to IEEE St’d 488-1978
Functional specifications SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, and C0
Protocol Conforms to IEEE St’d 488.2-1992
Address 0 to 30
