YOKOGAWA 2558A User Manual

iv
IM 2558A-01EN
Optional Accessories (Sold separately)
The following optional accessories are available for purchase separately.
For information about ordering accessories, contact your nearest YOKOGAWA dealer.
Item
Model/
Part No.
Min.
Q’ty
Safety
standard
Notes Manual No.
Measurement lead 758917 1 set 1000 V CAT II Safety terminal cable with 2 leads (red and black)
in a set. Length: 0.75 m. Rating: 1000 V, 32 A.
—
758933 1 set 1000 V CAT III Safety terminal cable with 2 leads (red and black)
in a set. Length: 1 m. Rating: 1000 V, 19 A.
—
B8506ZK 1 set 1500 V CAT I Safety terminal cable with 2 leads (red and black)
in a set. Length: 1 m. Rating: 1500 V, 19 A.
—
B8506WA 1 set — Current output cable with 2 leads (red and black)
in a set. Length: 1.5 m. Rating: 42 V, 80 A.
—
Alligator clip adapter
(small)
758922 1 set 300 V CAT II Safety terminal-to-alligator clip adapter. Red and
black, 1 pc each. Rating: 300 V, 15 A.
—
Alligator clip adapter
(large)
758929 1 set 1000 V CAT II Safety terminal-to-alligator clip adapter. Red and
black, 1 pc each. Rating: 1000 V, 32 A.
—
B8506ZL 1 set 1500 V CAT I Safety terminal-to-alligator clip adapter. Red and
black, 1 pc each. Rating: 1500 V, 32 A.
—
Fork terminal adapter 758921 1 set 1000 V CAT II Safety terminal-to-fork terminal adapter. Red and
black, 1 pc each. Rating: 1000 V, 20 A
—
BNC cable 366924 1 — BNC-BNC. Length: 1 m. Rating: 42 V. —
366925 1 — BNC-BNC. Length: 2 m. Rating: 42 V. —
Safety terminal adapter 758923 1 set 600 V CAT II Spring clamp type. Red and black, 1 pc. each.
Rating: 600 V, 10 A.
—
758931 1 set 1000 V CAT III Screw-in type. Red and black, 1 pc. each.
Rating: 1000 V, 36 A.
—
WARNING
• Use the accessories specied in this manual. Moreover, use the accessories of this product
only with Yokogawa products that specify them as accessories.
• Use the accessories of this product within the rated range of each accessory. When using
several accessories together, use them within the specification range of the accessory with
the lowest rating.
• Due to the structure of the product, it is possible to touch the metal parts of the fork terminal
adapter 758921. Be careful as this constitutes an electric shock hazard.
CAUTION
Use BNC cables 366924 and 366925 for the BNC I/O terminals.
French
AVERTISSEMENT
• Utiliser les accessoires spécifiés dans ce manuel. En outre, utiliser les accessoires de ce
produit uniquement avec des produits Yokogawa pour lesquels ils sont spécifiés comme
accessoires.
• Utilisez les accessoires de ce produit en fonction des valeurs nominales de chacun.
Lorsque vous employez plusieurs accessoires en même temps, utilisez les valeurs de
l’accessoire ayant les valeurs nominales les plus faibles.
