YOKOGAWA 2558A User Manual

5-10
IM 2558A-01EN
Output Value Display
The output from the voltage or current terminals is monitored and displayed.
Display update time: 200 ms
The output value is the sum of the output divider value and deviation.
Output value = Main setting × divider value + main setting × (– deviation)
Range Display Range
100 mV 0.00 mV to 144.00 mV
1 V 0.0000 V to 1.44000 V
10 V 0.000 V to 14.400 V
100 V 0.00 V to 144.00 V
300 V 0.00 V to 432.00 V
1000 V 0.0 V to 1440.0 V
100 mA 0.00 V to 144.00 mA
1 A 0.0000 V to 1.4400 A
10 A 0.000 V to 14.400 A
50 A 0.000 V to 72.000 A
5.6 Turning the Output On and Off
