YOKOGAWA AQ6370C User Manual

7-53
IM AQ6370C-17EN
Remote Commands
1
2
3
4
5
6
7
8
App
Index
:CALCulate:MARKer:MAXimum:SRLevel
Function Detects the peak level and sets it for the
reference level.
Syntax
:CALCulate:MARKer:MAXimum:SRLevel
Example
:CALCULATE:MARKER:MAXIMUM:SRLEVEL
Explanation This is a sequential command.
:CALCulate:MARKer:MAXimum:SRLevel:AUTO
Function Sets/queries ON/OFF of the function to
automatically detect the peak level and sets it
as the reference level.
Syntax
:CALCulate:MARKer:MAXimum:SRLevel:A
UTO<wsp>OFF|ON|0|1
Response 0 = OFF, 1 = ON
Example
:CALCULATE:MARKER:MAXIMUM:SRLEVEL:A
UTO ON
CALCULATE:MARKER:MAXIMUM:SRLEVEL:AU
TO? -> 1
Explanation • When this function is ON, the instrument
automatically detects the peak level of an
active trace wavelength each time a sweep
has ended, and sets it as the reference level.
• This is a sequential command.
:CALCulate:MARKer:MAXimum:SZCenter
Function Detects the peak wavelength and sets it as the
display center wavelength.
Syntax
:CALCulate:MARKer:MAXimum:SZCenter
Example
:CALCULATE:MARKER:MAXIMUM:SZCENTER
Explanation This is a sequential command.
:CALCulate:MARKer:MINimum
Function Detects the bottom and places the moving
marker on that bottom.
Syntax
:CALCulate:MARKer:MINimum
Example
:CALCULATE:MARKER:MINIMUM
Explanation This is a sequential command.
:CALCulate:MARKer:MINimum:LEFT
Function Detects the nearest bottom existing on the left
side of the current position of the moving marker
and places the moving marker on that bottom.
Syntax
:CALCulate:MARKer:MINimum:LEFT
Example
:CALCULATE:MARKER:MINIMUM:LEFT
Explanation • If the moving marker is OFF, an execution
error occurs.
• This is a sequential command.
:CALCulate:MARKer:MINimum:NEXT
Function Detects the lowest bottom that is above the
level of the current position of the moving
marker and places the moving marker on that
bottom.
Syntax
:CALCulate:MARKer:MINimum:NEXT
Example
:CALCULATE:MARKER:MINIMUM:NEXT
Explanation • If the moving marker is OFF, an execution
error occurs.
• This is a sequential command.
:CALCulate:MARKer:MINimum:RIGHt
Function Detects the nearest bottom existing on the right
side of the current position of the moving marker
and places the moving marker on that side.
Syntax
:CALCulate:MARKer:MINimum:RIGHt
Example
:CALCULATE:MARKER:MINIMUM:RIGHT
Explanation • If the moving marker is OFF, an execution
error occurs.
• This is a sequential command.
:CALCulate:MARKer:MSEarch
Function Sets/queries the type of the search function.
Syntax
:CALCulate:MARKer:MSEarch<wsp>
OFF|ON|0|1
:CALCulate:MARKer:MSEarch?
OFF|0: Sets the search function to single
search.
ON|1: Sets the search function to multi search.
Response 0 = OFF, 1 = ON
Example
:CALCULATE:MARKER:MSEARCH on
:CALCULATE:MARKER:MSEARCH? -> 1
Explanation • The search is executed as soon as you set
the search function.
• This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
:CALCulate:MARKer:MSEarch:SORT
Function Sets/queries the sort order of the multi search
detection list.
Syntax
:CALCulate:MARKer:MSEarch:SORT<wsp>
WAVelength|LEVel|0|1
:CALCulate:MARKer:MSEarch:SORT?
WAVelength|0: Wavelengths are displayed in
order starting from the shortest
wavelength.
LEVel|1: For the peak search, levels are
displayed in order starting from the
highest level. For the bottom search,
levels are displayed in order starting
from the lowest level.
Response 0 = OFF, 1 = ON
Example
:CALCULATE:MARKER:MSEARCH:SORT WAV
:CALCULATE:MARKER:MSEARCH:SORT? ->
0
Explanation • This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
7.6 Instrument-Specific Commands
