3. Cabling
3-67
TI 33Q01J10-01E
Analog I/O Modules AAM10, AAM11, AAM11B, AAM21, AAM21J,
APM11, AAM50, AAM51
B
A C
F030701.ai
1
2
16
1
2
16
I/O
channels
I/O
Terminals
AMN11
Temperature compensation
module/manual control
(for analog output module)
connector
Analog I/O module
Terminals
Temperature compensation/
manual control module
Analog I/O module
(slots 1 to 16)
Signal cables
Recorder output
connector (CN1)
AMN11
channels
Figure Analog I/O Module Cable Connection
Analog Input Modules AAM21, AAM21J for Resistance Temperature
Detector Signal Input
F030702.ai
B
A C
1
2
16
1
2
16
I/O
channels
I/O
A B C
To output 1 to 5 V DC signals to a recorder, connect cable AKB301 to connector CN1.
Connecting CN1 and terminal block TE16 via AKB301, for example, connects the
terminal block with a recorder.
channels
Figure AAM21, AAM21J (for Resistance Temperature Detector Signal Input) Cable Connection
May 18, 2007-00
