4. Installation Specifications
4-2
TI 33Q01J10-01E
Table Electrical Specifications (2/3)
Equipment
Input-voltage range
Max. power
consumption
(VA, A) (*1)
Heating
value J/h
(*2)
Voltage (V AC) Frequency (Hz)
PFCS field control station (excl. I/O)
100-120
50/60±3
200 VA
680 × 10
3
(190 W)
220-240 300 VA
24 V DC 9 A
PFCD field control station (excl. I/O)
100-120
50/60±3
200 VA
680 × 10
3
(190 W)
220-240 300 VA
24 V DC 9 A
ANS20/ANS50 Node Interface Unit
100-120
50/60±3
320 VA
540 × 10
3
(150 W)
220-240 320 VA
24 V DC 7.5 A
AND20/AND50 Dual-Redundant Node Interface Unit
100-120
50/60±3
320 VA
540 × 10
3
(150 W)
220-240 320 VA
24 V DC 7.5 A
ACB21 I/O Expansion Cabinet
(at maximum installation of RIO)
100-120
50/60±3
1600 VA
3240 × 10
3
(900 W)
220-240 1700 VA
24 V DC 42 A
AFS30S, AFG30S 19-inch Rack Mountable Type
Field Control Unit for FIO
100-120
50/60±3
250 VA
432 × 10
3
(120 W)
220-240 250 VA
24 V DC 4.5 A
AFS30D, AFG30D 19-inch Rack Mountable Type
Duplexed Field Control Unit for FIO
100-120
50/60±3
400 VA
720 × 10
3
(200 W)
220-240 410 VA
24 V DC 8 A
AFS40S, AFG40S with Cabinet (excluding node)
Field Control Unit for FIO
100-120
50/60±3
300 VA
540 × 10
3
(150 W)
220-240 330 VA
24 V DC 6 A
AFS40D, AFG40D with Cabinet (excluding node)
Duplexed Field Control Unit for FIO
100-120
50/60±3
450 VA
828 × 10
3
(230 W)
220-240 480 VA
24 V DC 10 A
AFS40S, AFG40S with Cabinet (including node)
Field Control Unit for FIO
100-120
50/60±3
1800 VA
4680 × 10
3
(1300 W)
220-240 2100 VA
24 V DC 53 A
AFS40D, AFG40D with Cabinet (including node)
Duplexed Field Control Unit for FIO
100-120
50/60±3
1800 VA
4680 × 10
3
(1300 W)
220-240 2100 VA
24 V DC 53 A
AFF50S 19-inch Rack Mountable Type Field Control
Unit for FIO
100-120
50/60±3
200 VA
432 × 10
3
(120 W)
220-240 230 VA
24 V DC 5.5 A
AFF50D 19-inch Rack Mountable Type Duplexed
Field Control Unit for FIO
100-120
50/60±3
200 VA
432 × 10
3
(120 W)
220-240 230 VA
24 V DC 5.5 A
ANB10S ESB Bus Node Unit
(at maximum installation of FIO)
100-120
50/60±3
200 VA
432 × 10
3
(120 W)
220-240 230 VA
24 V DC 5.5 A
*1: Power consumption in steady operation is indicated in VA (AC) or A (DC). When power consumption varies according to the installed number
of equipment, power consumption by the maximum number of units installed is listed.
*2: Heating value in steady operation is indicated in Joule/hour. When heating value varies according to the installed number of equipment,
heating value by the maximum number of units installed is listed.
Sep. 30, 2008-00
