4. Installation Specifications
4-3
TI 33Q01J10-01E
Table Electrical Specifications (3/3)
Equipment
Input-voltage range
Max. power
consumption
(VA, A) (*1)
Heating
value J/h
(*2)
Voltage (V AC) Frequency (Hz)
ANB10D Duplexed ESB Bus Node Unit
(at maximum installation of FIO)
100-120
50/60±3
200 VA
432 x 10
3
(120 W)
220-240 230 VA
24 V DC 5.5 A
ANR10S ER Bus Node Unit
(at maximum installation of FIO)
100-120
50/60±3
200 VA
432 x 10
3
(120 W)
220-240 230 VA
24 V DC 5.5 A
ANR10D Duplexed ER Bus Node Unit
(at maximum installation of FIO)
100-120
50/60±3
200 VA
432 x 10
3
(120 W)
220-240 230 VA
24 V DC 5.5 A
ACB41 I/O Expansion Cabinet
(at maximum installation of FIO)
100-120
50/60±3
1700 VA
4680 x 10
3
(1300 W)
220-240 1900 VA
24 V DC 46 A
YNT511/YNT522 single optical bus repeater (*4)
100-120
50/60±3
40 VA
80 x 10
3
(23 W)
220-240 55 VA
24 V DC 1 A
YNT512 single bus repeater (*4)
100-120
50/60±3
40 VA
80 x 10
3
(23 W)
220-240 55 VA
24 V DC 1 A
ACG10S Communication Gateway Unit
100-120
50/60±3
100 VA
270 x 10
3
(75 W)
220-240 100 VA
ABC11S Bus Converter
100-120
50/60±3
180 VA
288 x 10
3
(80 W)
220-240 180 VA
24 V DC 4 A
ABC11D Dual-Redundant Bus Converter
100-120
50/60±3
320 VA
540 x 10
3
(150 W)
220-240 320 VA
24 V DC 7.5 A
*1: Power consumption in steady operation is indicated in VA (AC) or A (DC). When power consumption varies according to the
installed number of equipment, power consumption by the maximum number of units installed is listed.
*2: Heating value in steady operation is indicated in Joule/hour. When heating value varies according to the installed number of
equipment, heating value by the maximum number of units installed is listed.
*3: The value obtained on the premise that the maximum power consumption of built-in PC is 400 VA. The service outlet is not
included.
*4: Power consumption and heating value double in the case of redundant system.
Maximum Power Consumption Depending on Installed Nodes (Model AND20)
Max. power consumption (VA)
No. of installed nodes 0 1 2 3 4 5 6
AFS20D 450 770 1060 1260 1440 1580 1700
ACB21 (Expansion Cabinet) 80 400 720 1000 1250 1440 1600
Note: Node load is at max. installation
