YOKOGAWA CENTUM CS 3000 User Manual

2. Transportation, Storage and Installation
2-10
TI 33J01J10-01EN
2.5 Installation
Before installation, be sure that anchor bolts, pedestals, and cable holes are provided
accordingtothecustomer’ssystemcongurationplans.Checkthatthepositionsof
holesontheoorttheanchorboltholesinthechannelbaseofeachpieceofequipment.
2.5.1 Installation on Floor

 

 
Check the position of front and back panels of the cabinet.

 󰀨

n Concrete Floor

3,200 N•cm tightening torque.
Equipment
Anchor bolts
F020501.ai
Figure Using Anchor Bolts
Apr. 21, 2017-00
