3. Cabling

3-70

TI 33J01J10-01EN

n Connecting Relay Board with Digital I/O Module



ADV551 is shown below.

CN1

F030611.ai

Connection with FG

ADV551+ATD5A adaptor

Yokogawa-specific cable AKB331

ARM55D

Figure Example of Relay Board Connection with Digital I/O Module

Oct. 5, 2018-00
