YOKOGAWA CENTUM CS 3000 User Manual

3. Cabling
3-94
TI 33J01J10-01EN
3.8 Signal Connections of N-IO I/O Unit (For RIO
System Upgrade)
This section describes the signal connection with the N-IO I/O units for RIO System
Upgrade.
3.8.1 N-IO I/O Unit Types
n I/O Modules installed into the Nest for I/O Adaptor

Table I/O Modules installed into the A2BA3D Nest for I/O Adaptor
Nest for I/O Adaptor model I/O module model
 A2MME041
 
3.8.2 Nest for I/O Adaptor
n Adaptors installed into the Nest for I/O Adaptor
Table Adaptors installed into the A2BA3D Nest for I/O Adaptor
Nest for I/O Adaptor model Adaptor model
A2BA3D

A2SAP105 Pulse Input Signal Adaptor



n Terminal type that can be select with Nest for I/O Adaptor
Table Terminal type Compatible with A2BA3D Nest for I/O Adaptor
Model Su󰀩xcode Terminal type
A2BA3D

3
M4 Screw
4
ELCO Connector
Oct. 5, 2018-00
