YOKOGAWA CENTUM CS 3000 User Manual

3. Cabling
3-6
TI 33J01J10-01EN
lSleeve Terminal Processing
Perform the following terminal processing for the primary power supply input with pressure clamp
terminal.

CAUTION
 
 
• Connect the cable properly by inserting the wires all the way into the pressure clamp
terminals.

󰀨
table.
F030202.ai
L1
L2
Sleeve with insulating coverCength of coating to strip
core cable
Figure Terminal Processing
Table Cable termination example of Sleeve with Insulating Cover
Nominal cross
sectional area
(mm
2
)
Length to strip
(mm)
Sleeve dimensions (mm)
Weidmüeller
model number No.
L1 L2
 10 14 8 
Apr. 21, 2017-00
