Carrying
This section describes how to carry cabinets.
Carrying Space
Carry cabinets into the location of installation without unpacking.
To carry them in on the second floor or upper floors using a crane, a scaffold of about 2500 by
4000 mm is required for placing as well as unpacking.
Table Required Entrance and Elevator Size
Console type HIS
Console type HIS
(LCD Dual Stacked)
Cabinet
Width 800 mm 800 mm 800 mm
Height 1500 mm 1900 mm 2400 mm
Depth 1600 mm 1600 mm 1000 mm
Max. loading capacity 150 kg 200 kg 400 kg
Passage
The passage must be wide enough as shown below. It must also be strong enough to withstand
the weight of the cabinet. Determine the passage according to the cabinet’s and carrier’s size
and weight.
• Carrying console type HIS in
1600 mm
800 mm
1500 mm min.
1500 mm
min.
F020103.ai
Height: Console height + Carrier height
• Carrying cabinet in
1000 mm
800 mm
1300 mm
min.
Height: Cabinet height + Carrier height
F020101.ai
1300 mm min.
Figure Passage Requirements
Sep. 30, 2008-00
