2. Transportation, Storage and Installation
2-17
TI 33J01J10-01EN
2.5.3 19-inch Rack Mount Devices
Before use, mount the following devices in a rack. AFV30S/AFV30D, A2FV50S/A2FV50D,
A2FV70S/A2FV70D, ANB10S/ANB10D, ANB11S/ANB11D, and ANT10U Unit for FIO and
AVR10D Duplexed V net Router and AW810D Wide Area Communication Router and
A2NN10D Node Interface Unit.
n Notes on Installation
CAUTION
lProviding Space for Heat Radiation
• Separate the top of the instrumentation board at least 100 mm away from the ceiling, and
2
• Keep at least 50 mm between the back of the equipment and the instrumentation panel or
wall.
Do not use any space between equipments for cable wiring or anything.
Apr. 21, 2017-00
To Next Page
