2. Transportation, Storage and Installation
2-54
TI 33J01J10-01EN
2.5.7 Desktop Equipment
There are PCs, printers, etc. as the devices used on the desks.
Keep a space of 100 mm radius or more around the connectors.
• Do not place the desk such as to expose the PC to direct sunlight or high humidity.
2.5.8 Installing Control Bus Interface Card
This section describes how to install VI702 Control Bus interface card. The card is
installed in the PCI Express slot of a IBM PC/AT compatible PC to connect it to the Control
Bus. The card permits you to use CENTUM VP system operation and monitoring functions
on the PC when used with the dedicated software.
SEE
ALSO
of the PC to be used for precise instructions.
33J50B10-01EN).
l Card Installation Procedure
1. Set a station address for the Control Bus interface card.
5. Insert the Control Bus interface card in the slot. Make certain that the card is properly set in
the slot.
SEE
ALSO
Mar. 29, 2019-00
To Next Page
