2. Transportation, Storage and Installation
2-28
TI 33Q01J10-01E
Providing Area for Servicing
Leave about at least 1000 mm of space at the front of the equipment for:
• Cabling to 19-inch rack mount devices, or I/O modules.
• Indicator lamp confirmation, making card settings, inspection, card mounting/dismounting,
and maintenance.
F020412.ai
Ceiling
Ventilation fan
Front
Servicing area
3 units or more
50 mm or more
100 mm or more
1000 mm or more
Figure Space Required for Rack-mount Equipment
Oct. 22, 2007-00
