2. Transportation, Storage and Installation

2-30

TI 33J01J10-01EN

Oct. 5, 2018-00

Mounting of Door Fan

Mount the door fan unit using the chassis of Rittal’s standard door fan unit.

Chassis lug

Door Fan Frame

F020516.ai

Door Fan Frame

Groove

Projection

Hole for mounting

Door Fan Unit

Figure Mounting of Door Fan frame Figure Mounting of Door Fan Unit
