1. System Installation Requirements
1-11
TI 33Q01J10-01E
Table Equipment Installation Specifications (2/2)
Item
Specifications
(except for LPCKIT, YPCKIT,
YAX101. YAX801, and ANR10
)
Specifications
(ANR10
)
Remarks
Temperature
Normal operation 0 to 50 °C
0 to 60 °C (Temperature
option: –20 to 70 °C)(*1)
Avoid direct sunlight.
Transportation/
storage
–20 to 60 °C
–20 to 60 °C (Temperature option:
–40 to 85 °C)
Avoid direct sunlight.
Humidity
Normal operation
10 to 90 %RH (In case of
AFF50
/ 5 to 95 %RH)
5 to 95 %RH No condensation
Transportation/
storage
10 to 90 %RH (In case of AFF50
/ 5 to 95 %RH)
5 to 95 %RH No condensation
Temperature
fluctuation
Normal operation Within ±10 °C/h Within ±10 °C/h –
Transportation/
storage
Within ±20 °C/h Within ±20 °C/h –
Power
source
Voltage range
100-120 V AC ±10 %
220-240 V AC ±10 %
24 V DC ±10 %
(including ripple)
100-120 V AC ±10 %
220-240 V AC ±10 %
24 V DC ±10 %
(including ripple)
–
Frequency 50/60 ±3 Hz 50/60 ±3 Hz –
Distortion factor 10 % or less 10 % or less –
Peak value
125 V or larger (for 100-120 V AC)
274 V or larger (for 220-240 V AC)
125 V or larger (for 100-120 V AC)
274 V or larger (for 220-240 V AC)
–
Momentary failure
20 ms or less
(for 100-120/220-240 V AC)
20 ms or less
(for 100-120/220-240 V AC)
With rated voltage
supplied
Withstanding voltage
1500 V AC for 1 minute
(for 100-120/220-240 V AC)
1500 V AC for 1 minute
(for 100-120/220-240 V AC)
Between power &
ground terminals
Insulation resistance
20 Mohms at 500 V DC 20 Mohms at 500 V DC
Between power &
ground terminals
Grounding
100 ohms or less 100 ohms or less
Independent
grounding
Noise
Electric field
3 V/m or less (26 MHz to 1.0 GHz)
3 V/m or less (1.4 to 2.0 GHz)
1 V/m or less (2.0 to 2.7 GHz)
3 V/m or less (26 MHz to 1.0 GHz)
3 V/m or less (1.4 to 2.0 GHz)
1 V/m or less (2.0 to 2.7 GHz)
–
Magnetic field
30 A/m or less (AC)
400 A/m or less (DC)
30 A/m or less (AC)
400 A/m or less (DC)
Earth magnetism
not included in DC
magnetic field
Static electricity
4 kV or less (direct discharge)
8 kV or less (aerial discharge)
4 kV or less (direct discharge)
8 kV or less (aerial discharge)
In accordance with
IEC 1000-4-2
Vibration
Vibration
Displacement amplitude:
0.25 mm or less (1 to 14 Hz)
Acceleration: 2.0 m/s
2
or less (14 to 100 Hz)
Displacement amplitude:
0.25 mm or less (1 to 14 Hz)
Acceleration: 2.0 m/s
2
or less (14 to 100 Hz)
Quake resistance 4.9 m/s
2
or less 4.9 m/s
2
or less
Vibration during
transportation
For cabinets:
Horizontal: 2.9 m/s
2
or less
Vertical: 4.9 m/s
2
or less
For others:
Horizontal: 4.9 m/s
2
or less
Vertical: 9.8 m/s
2
or less
Horizontal: 4.9 m/s
2
or less
Vertical: 9.8 m/s
2
or less
In packed condition
Impact
Transportation impact
Horizontal: 49 m/s
2
or less
Vertical: 98 m/s
2
or less
Horizontal: 49 m/s
2
or less
Vertical: 98 m/s
2
or less
In packed condition
Dust
0.3 mg/m
3
or less 0.3 mg/m
3
or less –
Corrosive gas
Ordinary office level
In case of AFF50
/
ISA S71.04.G2
(ISA G3 option: ISA S71.04.G3)
ISA S71.04 G2
(ISA G3 option:
ISA S71.04 G3)
–
*1: When an AAP149, AAP849, ADV157, ADV557, ADV161, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569,
ALR111, ALR121, ALE111, ALF111 and ALP111 is installed, the ambient temperature should range from 0 to 50 °C.
Sep. 30, 2008-00
