2.5.6 Example of Mounting to General Purpose Cabinet /
Junction Box
examples, or when changing the conditions explained later, please carry out thermal design for
n Cabinet for FIO System
l Mounting to Cabinet Using ACUKT1
using the Cabinet Utility Kit (ACUKT1).
CabinetSpecication
Cabinet Utility Kit (ACUKT1) can be used for mounting to a Rettal TS8 cabinet with the
Operating Temperature
• The ambient temperature of the cabinet should be 50°C or less.
Mounting Conditions
• Maximum number of mounted units
One unit can be mounted either at the front or rear of the cabinet (max. one unit).
Node unit:
• Use the door fan that is included in ACUKT1.
it.
• Mount the appropriate number of node fan units in accordance with the number of units
IMPORTANT
