3. Cabling
3-23
TI 33Q01J10-01E
An example of installing an ER Bus Node Unit in a general-purpose cabinet along with an AEP7D
Primary Power Supply Bus Unit is shown.
L
N
L
N
TM2 100-120V AC,
TM1 100-120V AC,
ANR10S/ANR10D
F030422.ai
AEP7D
ANR10S/ANR10D
General-purpose
Cabinet
Figure Example of Installing ANR10S/ANR10D in a General-purpose Cabinet (Dual AC Power Supply
Line)
Feb 1, 2009-00
